SUPPORT OEM & ODM
Single Cylinder Gasoline Engines for Global Distributors
We supply reliable Horizontal Shaft Single Cylinder Engine with flexible OEM and ODM options, featuring stable performance, fuel efficiency, and long service life. Designed for generators, agricultural machinery, and light industrial equipment, our engines meet the needs of global distributors and equipment manufacturers.
Not for Retail Sale
Wholesale Only
Features
- Easy starting design with optimized compression release system, reducing pull resistance and ensuring smooth and reliable ignition.
- Robust single-cylinder structure with proven OHV technology, delivering stable power output and long-term durability.
- Low vibration performance achieved through optimized crankshaft balance and horizontal shaft layout, ensuring smooth and stable operation under continuous load.
- Optimized combustion chamber design improves fuel efficiency while reducing fuel consumption and exhaust emissions.
- Large-capacity air filtration system with effective dust protection, minimizing cylinder wear and extending engine service life.
If you need more product models or customized specifications, please feel free to contact us.
WHAT SETS US APART?
Horizontal Shaft Single Cylinder Engine Comparison Chart
| Model | FP156F | FP168FA | FP168FB | FP170F(E) | FP180F(E) | FP188F(E) | FP190F(E) | FP192F(E) | FP196F(E) |
|---|---|---|---|---|---|---|---|---|---|
| Engine type | Single cylinder, Air cooled, 4-stroke, OHV | ||||||||
| Displacement (cc) | 98 | 163 | 196 | 212 | 302 | 389 | 420 | 459 | 622 |
| Net Power (kW/rpm) | 2.2 | 4.1 | 4.8 | 5.2 | 6.2 | 7.8 | 9.0 | 10 | 13 |
| Bore x Stroke (mm) | 56×40 | 68×45 | 68×54 | 70×55 | 80×60 | 88×64 | 90×66 | 92×69 | 96×86 |
| Net Torque (Nm / R / Min) | 5.0/2500 | 10.08/2500 | 12.5/2500 | 12.5/2500 | 18.5/2500 | 25/2500 | 26.5/2500 | 30.5/2600 | 38/2800 |
| Starting System | Recoil | Recoil/Electric | Recoil/Electric | Recoil/Electric | Recoil/Electric | Recoil/Electric | Recoil/Electric | Recoil/Electric | Recoil/Electric |
| Lubrication System | Splash | Splash | Splash | Splash | Splash | Splash | Splash | Splash | Splash |
| Air Filter | Half dry, dual-filter element | ||||||||
| Engine Oil Capacity (L) | 0.3 | 0.6 | 0.6 | 0.6 | 0.95 | 1.1 | 1.1 | 1.1 | 1.6 |
| Fuel Tank Capacity (L) | 1.6 | 3.6 | 3.6 | 3 | 4.6 | 6.5 | 6.5 | 6.5 | 6.5 |
| Net Weight (kg) | 11 | 17 | 18 | 19 | 29 | 31 | 32 | 32 | 42 |
| Product Dimension (L × W × H) (mm) |
350×300×350 | 390×330×380 | 390×330×380 | 390×330×380 | 400×445×440 | 465×415×450 | 465×415×450 | 490×460×450 | 560×450×495 |
| Loading Qty (20GP/40HQ) | 744/1404 | 630/1260 | 630/1260 | 630/1260 | 350/870 | 300/625 | 300/625 | 300/600 | 200/525 |
Key Technologies Inside Fullas Horizontal Shaft Single Cylinder Engine
Fullas horizontal shaft single cylinder gasoline engines are engineered for stable power transmission, durable operation, and cost-effective performance. Covering displacement options from 196cc to 420cc, these engines deliver reliable output of up to 9.0 kW, making them ideal for generators, water pumps, agricultural machinery, and light industrial equipment requiring continuous and stable power.
Multiple Displacement Options for Different Equipment Needs
The FP156F to FP196F(E) series covers a wide displacement range from 98cc to 622cc, making it suitable for various applications including generators, pumps, agricultural equipment and construction machinery. Users can select compact low-power models or high-output industrial engines depending on actual operating requirements.
Reliable Recoil & Electric Starting System
Most models from FP168FA upward support recoil/electric start combinations, improving convenience in both daily operation and commercial environments. The FP190F(E), FP192F(E) and FP196F(E) provide more stable starting performance for heavy-duty equipment and high-load applications.
Stable OHV Air-Cooled Engine Structure
All models adopt single-cylinder, air-cooled, 4-stroke OHV engine technology, helping improve combustion efficiency and cooling performance. This structure supports stable operation under continuous workloads while reducing maintenance complexity.
High Torque Output at Low Speed
The larger displacement models such as FP188F(E), FP190F(E) and FP196F(E) provide strong torque performance from 25Nm up to 38Nm, allowing the engines to maintain stable output when driving generators, pressure washers or agricultural machinery under load.
Dual-Filter Air Intake Protection
The FP170F(E) and above models use half-dry dual-filter air filter elements, helping improve dust resistance and intake cleanliness in outdoor working environments. This design is especially suitable for construction sites, farms and dusty industrial conditions.
Compact Structure with Good Loading Efficiency
Despite covering up to 622cc displacement, the engines maintain relatively compact dimensions and optimized container loading quantities. Smaller models such as FP156F and FP168 series support high loading efficiency up to 744/1404 pcs (20GP/40HQ), helping reduce shipping and storage costs for OEM and bulk export customers.
